M542 stepper motor driver for stepper motor

Product Categories

Jiangsu Changzhou Sutai Electrical Appliance Co.,Ltd

Contact Now

Place of Origin : China

Brand Name : Sutai

Certification : ISO,CE,ROHS

Model Number : ST-M542

MOQ : 1

Price : 30

Packaging Details : EXPORT PACKING

Delivery Time : 3~30DAYS

Payment Terms : TT

Supply Ability : 10000SETS/PER MONTH

Contact Now

stepper motor driver tb6560(m542) 1.5A-4.5A

M542 stepper motor driver for stepper motor

Port instructions

ST-M542 Driver Pin Port Description
PUL+	Positive signal input terminal , connect +5V
PUL-	Pulse signal input port
DIR+	Positive signal input terminal , connect +5V
DIR-	Direction input signal port
ENA+	Positive signal input terminal , connect +5V
ENA-	Enable inputs
A+ A- B+ B-	Connect two-phase hybrid motor windings
DC+ DC-	Input voltage DC 24-40VDC
SW1~SW3	Drive current portfolio setting
SW4	Full flow semi-flow setting
SW5~SW8	Drive Subdivision combination setting

Note : 1,When the input signal is greater than 5V , Need PUL, DR,ENA front end of resistance , General 12V plus 1.2K, 24V plus 2K resistance

Current setting

Subdivision setting (SW5-SW8)

SW5

SW6

SW7

SW8

subdivision
